The Ultra-Shield TC1 Small Adult Seat is a full containment seat constructed from .100 5052 aluminum. With new low profile shoulder-to-head connectors, it provides safety and comfort. The TC1 Small Adult Seat is available in sizes 13", 14" or 15".
- Constructed from .100 5052 aluminum
- 10º Layback
- C-Channel Stiffener around torso
- Reinforced Halo and shoulders
- Full wrap around cover on head surround to cover side head foam
- New low profile shoulder-to-head connectors
- Small Adult Seat is available in sizes 13", 14" or 15"
- 18" Shoulder Belt Height, Right Rib at 13", Left Rib at 12”
- High density, closed cell, impact absorbing foam in Head and Halos
- Made in Flint, TX USA!
Specifications
| Brand |
Ultra-Shield |
|
Product Line
|
TC1 Small Adult
|
|
Front / Rear
|
Front
|
|
Full Containment
|
Yes
|
|
Highback / Lowback
|
Highback
|
|
Widths
|
13" - 15"
|
|
Thickness
|
0.1 in
|
|
Layback Degree
|
10 Degree
|
|
Shoulder Support Included
|
Yes
|
|
Rib Support
|
Yes
|
|
Rib Support Side
|
Left / Right
|
|
Head Support
|
Yes
|
|
Harness Openings
|
Yes
|
|
Cover Mounting Method
|
Snap-On
|
|
Cover Included
|
Yes
|
|
Cover Material
|
Cloth
|
|
Cover Color
|
Black
|
|
Material
|
Aluminum
|
|
Color
|
Natural
|
|
Finish
|
Natural
|
|
Quantity
|
Kit
|
Seats
| Size |
Part Number |
| 13" |
T1SA310K |
14"
|
T1SA410K |
| 15" |
T1SA510K |
