RaceQuip 6-Point SFI HNR Latch & Link Harness SetRQP718008 (Not in stock)
The RaceQuip Latch & Link 6-point HANS/HNR racing harness set has twin individual shoulder belts that are reduced to 2" above the adjusters so that you can more easily accommodate a HANS device or head and neck restraint.
These belts are manufactured using premium 3" polyester webbing and drop-forged steel hardware to exceed the SFI 16.1 rating. Shoulders adjust from 20" to 62" and the lap belt adjusts from 20" to 60". All RaceQuip 718 series belts come as a "pull down lap" design, which means that the lap belts must be pulled down and away from the center latch & link buckle mechanism to tighten.
All RaceQuip Latch & Link harness sets for motorsports are distinguished by a pivoting "hammer," called a Duckbill, which is located on the lap belt and locks all of the belts into place by snapping down into a detent. Both shoulder belts and the dual sub-belt are hooked over the link; the link is inserted into the latch on the lap belt; the Duckbill is then brought down into and over the link, securely holding all of the pieces in place.
Since RaceQuip seat belt sets are "double adjustable", lengths are simply adjusted on either end for ease of installation. Using the included three bar slide you can mount the belts by either wrapping them around a roll bar or by bolting them in place with the supplied ends. Snap hook ends and eyebolts are sold separately if the user wishes to install belts in that manner
- 6-Point Latch & Link Harness
- Pull-down lap belts
- Pivoting hammer (duckbill) locks all belts into place
- Double-adjustable lengths by adjusting on either end for ease of installation
- Wrap-around or bolt-in installation
- Shoulders adjust from 20" to 62"
- Lap belt adjusts from 20" to 60"
- SFI 16.1
