Extreme Series batteries combine the benefits of enormous cranking power and deep cycle reserve power, possible through the use of flat plates manufactured from 99.99% pure lead, not lead alloy. Pure lead plates may be made thinner, allowing more plates, which are then densely packed, resulting in twice the power of conventional batteries.
Batteries additionally use dry-cell Absorbed Glass Mat (AGM) technology to contain acid, allowing the battery to be installed on its side, if desired.
- Battery, Extreme Series, AGM, 12V, 155 Cranking amps, Threaded Terminals, Top Terminals, 5.43 in L x 3.98 in H x 3.39 in W
- Sold as Each
- Brand: Odyssey Battery - Part Number: PC310
Notes: “T” suffix stands for SAE terminals. “MJ” stands for metal jacket. “DT” signifies top and side SAE terminals. Battery Ratings: PHCA signifies pulse current (5 second starting power). CCA signifies cold start performance (30 seconds of cranking at 0°F).
Specifications
|
Brand
|
Odyssey Battery
|
|
Part Number
|
PC310
|
|
Product Line
|
Extreme Series
|
|
Volts
|
12V
|
|
Deep Cycle
|
No
|
|
Top Terminal
|
Yes
|
|
Top Terminal Style
|
Threaded
|
|
Positive Top Terminal Size A
|
4mm x 0.70
|
|
Negative Top Terminal Size A
|
4mm x 0.70
|
|
Battery Type
|
AGM
|
|
Cold Cranking Amps
|
100
|
|
Pulse Cranking Amps
|
310
|
|
Cranking Amps
|
155
|
|
Reserve Capacity in Minutes
|
9
|
|
Positive Post Location
|
Right Front
|
|
Negative Post Location
|
Left Front
|
|
Case Material
|
Plastic
|
|
Case Color
|
Black
|
|
Top Color
|
Red
|
|
Case Graphics
|
Extreme Series
|
|
Battery Length
|
5.43 in
|
|
Battery Height
|
3.98 in
|
|
Battery Width
|
3.39 in
|
|
Battery Weight
|
5.9 lbs
|
|
Charger Included
|
No
|
|
Terminal Bolts Included
|
Yes
|
|
Quantity
|
Each
|
